Frame 2M wihtout screws 71mm - 09603.1

Pdf
Vimar - 09603.1 - Frame 2M wihtout screws 71mm
Vimar - 09603.1 - Frame 2M wihtout screws 71mm

09603.1
Wiring devices / Traditional wiring devices / NEVE UP / Mounting frames

Frame 2M wihtout screws 71mm
2-module mounting frame, screw-less, for flush mounting boxes with distance between centres of 60 mm, modular with distance between centres of 71 mm

产品状态
3 - Active

您可能也感兴趣

07935.1
07935.1 - Screw for frame fixing - 24mm
07937
07937 - Screw for frame fixing - 35mm
07939
07939 - Screw for frame fixing - 50 mm
09602.1
09602.1 - Frame 2M +claws 71mm

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with claw
With nail
No
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated

00. CE Marking - EU

29. QCERT - Colombia

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352654907
1 NR
7.3x7.3x2.5 [cm]
13.95 [g]
Barcode Qty 50 NR
8007352654914
50 NR
28.6x24.8x9.6 [cm]
836.4 [g]
Barcode Qty 300 NR
8007352654921
300 NR
62x26x30 [cm]
5,543.8 [g]
