Mounting frame Plana/Neve+screws - 09623

Pdf
Vimar - 09623 - Mounting frame Plana/Neve+screws
Vimar - 09623 - Mounting frame Plana/Neve+screws

09623
Wiring devices / Traditional wiring devices / NEVE UP / Mounting frames

Mounting frame Plana/Neve+screws
3-module mounting frame with screws, for the installation of Plana devices in Neve cover plates, for 3-module mounting boxes

产品状态
3 - Active

您可能也感兴趣

07935.1
07935.1 - Screw for frame fixing - 24mm
07937
07937 - Screw for frame fixing - 35mm
07939
07939 - Screw for frame fixing - 50 mm
09613
09613 - Frame 3M +screws

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

29. QCERT - Colombia

43. UKCA mark - Great Britain

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352550711
1 NR
11.8x6.5x1.7 [cm]
20.8 [g]
Barcode Qty 20 NR
8007352550728
20 NR
28x15.2x9.75 [cm]
515 [g]
Barcode Qty 140 NR
8007352705487
140 NR
57.5x22.5x30 [cm]
3,605 [g]
