Vimar - 09613 - Frame 3M +screws

09613
Wiring devices / Traditional wiring devices / NEVE UP / Mounting frames

Frame 3M +screws
3-module mounting frame, with screws, for 3-module mounting boxes

产品状态
3 - Active

您可能也感兴趣

07935.1 - Screw for frame fixing - 24mm

07937 - Screw for frame fixing - 35mm

07939 - Screw for frame fixing - 50 mm

09614 - Frame 4M +screws

09617 - Frame 7M +screws

09623 - Mounting frame Plana/Neve+screws

09606 - Horizontal frame 2centralM+screws

09607 - Vertical frame 2centralM+screws

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
3

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 10 NR

条形码

8007352298750

1 NR

11.8x6.5x1.7 [cm]

20.27 [g]

8007352298941

10 NR

11.8x6.5x17 [cm]

204.53 [g]

8007352298767

200 NR

35x33.5x24.5 [cm]

4,644 [g]
