Surface-box 3M 30mm depth Idea grey - 09976.14

09976.14

Enclosures and mounting boxes / Surface mounting boxes / Others

Surface-box 3M 30mm depth Idea grey
3-module surface mounting box, 30 mm depth, for Eikon, Idea and Plana devices with relevants mounting frame and cover plates, Idea grey. To be installed on insulating non-perforated or metallic with earth connection surfaces. Idea series: suitable only for Classica cover plates. Eikon series: suitable only for Eikon Chrome cover plates

产品状态
3 - Active

Class group
Connection devices
Class
Box/housing for surface mounting on the
Max. conductor cross section
0
Equipped with
None
Shape
Rectangular
Mounting method
Wall-/ceiling mounting
Mounting in the soil
No
Mounting under water
No
For tube diameter
20/25 mm
Inlet from the rear
Yes
Length
84,00 mm
Width
121,50 mm
Depth
30,00 mm
Diameter
0 mm
Tackable
No
Number of inlets
4
Type of housing feed-through
None
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Grey
Degree of protection (IP)
IP20
Cover model
Other
Transparent cover
No
Cover attachment
Screwed
Castable
No
Casting compound included
No
Sealable
No
Rated insulation voltage Ui
450 v
Circuit integrity
None
With screening
No
Weatherproof
No
Working temperature
0 - 60 °C
Explosion-tested version
No
For Ex-zone gas
None
For Ex-Zone dust
None
最小订单数量: 5 NR

条形码

8007352138971
1 NR
12.1x8.4x3 [cm]
34.67 [g]
8007352138988
5 NR
19x14.3x9.5 [cm]
194.61 [g]
