1-button a/v aluminium cover plate代码 13K1

13K1

ELVOX Door entry system / 2F/2F+ video door entry system / Outdoor stations / 1300 series

1-button a/v aluminium cover plate

Surface or flush mounting audio-video cover plate, with facility for adding another R131 button, for use with the button built into units 68TU/K, 68TC/K and 68TU/K93, supplied with surface mounting box and flush mounting box, electropolished anodized aluminium. Surface mounting dimensions: 100x168x37. Dimensions: da incasso 100x168x23 + 12 mm

产品状态

3 - Active

• 文件与下载
• ETIM技术数据
• 证书
• 供应数据
• 问题与回答

单, 说明书, 文档

• Multilanguage installer manual (5142 kb)
• Label printer module for entrance panels (981 kb)

---

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Communication technique (components and systems)

Class
Mounting frame for door station

Material
Aluminium

Colour
Silver

Mounting method
Other

Width
100,70 mm

Height
173,40 mm

Depth
62,80 mm

00. CE Marking - EU

32. FCC - USA

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

---

条形码

8013406217271

1 NR

22x12x8 [cm]

479 [g]

问题：	What is the IP protection degree of the product?
回答：	The protection degree is IP54

---
