1P 10AX 1-way switch 2M Silver - 14000.2.SL

Pdf

Vimar - 14000.2.SL - 1P 10AX 1-way switch 2M Silver

14000.2.SL

Plana Silver / Devices / Basic devices

1P 10AX 1-way switch 2M Silver
1P 10 AX 250 V~ 1-way switch, lightable, replaceable button, Silver - 2 modules. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Off switch 1-pole

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
2

Push button switch
Yes

Number of rockers
1

Mounting method
Flush mounted (plaster)

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Lacquered

Surface finishing
Glossy

Colour
Silver

RAL-number (similar)
9006

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 v

Rated current
10,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Width of device
44,80 mm

Height of device
49,00 mm

Depth of device
38,40 mm

Built-in depth
24,00 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

13. SNI - Indonesia

14. TSE - Turkey

15. CCC - China

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352319851

1 NR

5.1x4.3x5.3 [cm]

36.6 [g]

8007352319868

20 NR

26.9x11.6x9 [cm]

810.07 [g]
