1P 16AX 2-way switch Silver - 14005.SL

Pdf

14005.SL
Wiring devices / Traditional wiring devices / PLANA / Devices

1P 16AX 2-way switch Silver
1P 16 AX 250 V~ 2-way switch, lightable, replaceable button, Silver. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
22,30 mm
Device height
49,00 mm
Device depth
38,40 mm
Built-in depth
24,00 mm

00. CE Marking - EU

13. SNI-MGI - Indonesia

14. TSE - Turkey

19. NOM - Mexico

20. IQC - Argentina

29. QCERT - Colombia

31. TISI - Thailand

34. PSE - Japan

37. Marking - Morocco

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352320031
1 NR
4.1x2.8x5.3 [cm]
30.2 [g]
Barcode Qty 50 NR
8007352320048
50 NR
21.6x11.6x14.3 [cm]
1,604 [g]
Barcode Qty 500 NR
8007352640801
500 NR
57.5x22.5x30 [cm]
17,080 [g]
Barcode Qty 10,500 NR
8007352750326
10,500 NR
120x80x105 [cm]
358,680 [g]
