IoT connected dimmer mechanism 220-240V - 14595.0

Pdf

14595.0
Wiring devices / View Wireless wiring devices / PLANA / Devices

IoT connected dimmer mechanism 220-240V

  • Compatible with both LE and TE dimmable lamps
  • Also configurable as a 1-way switch pending the installation of a dimmable lamp
  • Bluetooth mode compatible with Amazon Alexa, Google Assistant, Apple Homekit and IFTTT voice assistants, via the dedicated Vimar gateway
  • Zigbee mode compatible with the Amazon Alexa voice assistant, via Amazon Zigbee hub

产品状态
3 - Active

您可能也感兴趣

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Other
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Glossy
Colour
Green
RAL-number (similar)
9003
Label space/information surface
No
Illumination
Yes
Function lighting
Other
Type of lighting
LED not exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
240 V
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
22,30 mm
Device height
49,00 mm
Device depth
47,10 mm
Built-in depth
36,50 mm
Min. depth of built-in installation box
41,00 mm
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
Yes

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

43. UKCA mark - Great Britain

92. RoHS UAE

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352707207
1 NR
6x5.4x5.2 [cm]
44.3 [g]
Barcode Qty 60 NR
8007352710429
60 NR
37.5x30x13.5 [cm]
3,150.6 [g]
