Frame 2M BS - 14607

Pdf

14607
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M BS
2-module mounting frame, with screws, for British standard mounting boxes

产品状态
3 - Active

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

08. ASTA - UK

29. QCERT - Colombia

最小订单数量: 40 NR

8007352383494

1 NR

8.25x8.25x1.63 [cm]

42.5 [g]

8007352383500

40 NR

28.4x18.4x13.7 [cm]

1,700 [g]

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
