14619
Wiring devices / Traditional wiring devices / PLANA / Mounting frames
Frame 6(3+3)M +screws
4x4 in (6-module 3+3) mounting frame, with screws, for 09996 flush mounting boxes
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
3
3
Number of modules vertical (module system)
2
2
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 10 NR
条形码
8007352236240
1 NR
11.8x12.7x2.17 [cm]
40.4 [g]
8007352236257
10 NR
24.4x13.9x10.1 [cm]
504.33 [g]
8007352645028
40 NR
30.5x26x22 [cm]
2,356 [g]
