1P 10AX 1-way switch white - 16000.B

Pdf
Vimar - 16000.B - 1P 10AX 1-way switch white
Vimar - 16000.B - 1P 10AX 1-way switch white
16000.B

Idea / Devices / Basic devices

1P 10AX 1-way switch white
1P 10 AX 250 V~ 1-way switch, white. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
24,80 mm
Height of device
50,10 mm
Depth of device
36,50 mm
Built-in depth
23,30 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

28. NSW - Australia

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352066670
1 NR
4.1x2.8x5.3 [cm]
27.33 [g]
Barcode Qty 50 NR
8007352066687
50 NR
21.4x11.6x14.2 [cm]
1,455.2 [g]
Barcode Qty 500 NR
8007352637047
500 NR
57.5x22.5x30 [cm]
15,520 [g]
