Vimar - 16273 - 2P+E 16A P17/11 outlet+C16 CB grey

16273
Wiring devices / Traditional wiring devices / IDEA / Devices

2P+E 16A P17/11 outlet+C16 CB grey
2P+E 16 A 250 V~ SICURY Bpresa socket outlet, Italian standard P17/11 interlocked with 1P+N C 16 circuit breaker, supply voltage 230 V~ 50 Hz, breaking capacity 3000 A, grey - 2 modules

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Socket outlet

Model
Italian type Bipasso

Number of units
2

Number of modules (module system)
2

Number of socket outlets switchable
1

Imprint/indication
None

Connection type
Screwed terminal

With hinged lid
No

With enhanced contact protection
Yes

Label space/information surface
Yes

Colour
Grey

RAL-number (similar)
7015

Metallic colour
No

Transparent
No

Lockable
No

Eject-mechanism
No

Insulated mounting
No

With function lighting
No

With orientation lighting
No

Over voltage protection
No

Fault current protection
No

With miniature fuse
No

Mounting method
Flush-mounted

Type of fastening
Snap mounting (engagement)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

With loop through function
No

With on/off switch
Yes

Rotated central insert
No

Nominal current
16 A

Nominal voltage
230 V

Frequency
50,00 - 50,01 HZ

Suitable for degree of protection (IP)
IP20

Impact strength
Other

Device width
49,80 mm

Device height
50,10 mm

Device depth
57,30 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 5 NR

条形码

8007352113053

1 NR

6x5.4x5.3 [cm]

98.8 [g]

8007352113060

5 NR

17.2x13.1x6 [cm]

552 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
