Frame 2M for panel mounting - 16772

Pdf
Vimar - 16772 - Frame 2M for panel mounting
Vimar - 16772 - Frame 2M for panel mounting

16772
Wiring devices / Traditional wiring devices / IDEA / Mounting frames

Frame 2M for panel mounting
2-module mounting frame, screws, for panel mounting, grey

产品状态
3 - Active

您可能也感兴趣

16776.AU
16776.AU - Flush mounting box for panel mounting

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
Mounting method of the module inserts
Back side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
2
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352082489
1 NR
3.4x13.2x2.2 [cm]
13.47 [g]
Barcode Qty 10 NR
8007352083974
10 NR
18.8x13.8x7 [cm]
191.8 [g]
Barcode Qty 100 NR
8007352717640
100 NR
37.5x30x21 [cm]
1,918 [g]
