16776.AU
System infrastructure / Enclosures and control units / Connector block boxes / Flush mounting
Flush mounting box for panel mounting
Flush mounting box for panel mounting frames (GW 960 °C), black
产品状态
3 - Active
图纸
Class group
Connection material (electrotechnical)
Connection material (electrotechnical)
Class
Box/housing for built-in mounting in the wall/ceiling
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Other
Other
Shape
Rectangular
Rectangular
Construction type
Device connection box (round/square)
Device connection box (round/square)
Model
Single
Single
Provided with revolving ring
No
No
Couplable
No
No
Equipped with
None
None
Diameter
25 mm
25 mm
Length
54,00 mm
54,00 mm
Width
29,00 mm
29,00 mm
Depth
0,00 - 42,20 mm
0,00 - 42,20 mm
Inner depth
36,20 mm
36,20 mm
For number of electric fittings
1
1
Mounting switching equipment
Spread
Spread
With screws
No
No
Housing feed-through by break-out opening
Yes
Yes
Housing feed-through by seal membrane
No
No
Housing feed-through by nozzle
No
No
Housing feed-through by step membrane
No
No
For tube diameter
20/25 mm
20/25 mm
Suitable for cable diameter
0 - 25 mm
0 - 25 mm
Pipe locking
No
No
Pipe locking optional
No
No
Inlet from the rear
Yes
Yes
Number of inlets
3
3
Number of included spouts
0
0
Material
Plastic
Plastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Colour
Black
Black
Degree of protection (IP)
IP40
IP40
Cover model
None
None
Transparent cover
No
No
Cover attachment
Other
Other
Sealable
No
No
With screening
No
No
Air tight
No
No
Max. conductor cross section
0
0
Number of poles of the clamp
0
0
Clamp position fixed
No
No
Luminaire hook mounting
No
No
Nozzle
None
None
Special application
None
None
最小订单数量: 12 NR
条形码
8007352082496
1 NR
2.9x5.4x4.2 [cm]
9.6 [g]
8007352084094
12 NR
14.2x9.8x9.1 [cm]
159.93 [g]
