Frame 2reducedM+claws for ø60mm - 17082

Pdf

17082
Wiring devices / Traditional wiring devices / IDEA / Mounting frames

Frame 2reducedM+claws for ø60mm
2-reduced-module mounting frame, with claws, for ø 60 mm round flush or 09971 surface mounting boxes

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with claw
Mounting method of the module inserts
Back side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

43. UKCA mark - Great Britain

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352045514
1 NR
8.5x7.5x1.5 [cm]
23 [g]
Barcode Qty 50 NR
8007352006218
50 NR
31x24.8x8.7 [cm]
1,324.67 [g]
问题: Can reduced 2M mounting frames be fitted with 16A German socket outlets?
回答: To install a 16A German socket outlet on a reduced Idea module, there is a dedicated article: 2P+E 16A German SICURY socket outlet grey - 17038
