KNX outdoor transponder reader grey
Transponder card reader for installation outside rooms, KNX standard, 2 NO 4 A 24 V~ relay outputs, 2 inputs, power supply 12-24 V~ 50-60 Hz and 12-24 Vdc (SELV), grey - 3 modules. Supplied without transponder card

产品状态
3 - Active

Class group
Installation bus systems
Class
Access control unit for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
With bus connection
Yes

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352450998
1 NR
11.2x9.6x9.8 [cm]
147.2 [g]
问题: What can I control with the actuators located on the devices?
回答: In the external transponder reader, the internal transponder reader and the thermostat, you can control a maximum load of 24V, 2A (see instruction sheets). While for the Input/Output module, the relays control a maximum 240V, 16A (see instruction sheets).
