Rolling shutter IoT connected mechanism
View Wireless connected electronic control device for 1 roller shutter with slat orientation and change-over relay output for cosφ 0,6 motor 2 A 100-240 V~ 50/60 Hz, local or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system andZigbee 3.0 standard, 1 input for external push button to recall a scenario, favourite position recall function, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, to be completed with two interchangeable 1-module Arké half-buttons

  • Configuration from View Wireless App for Bluetooth technology system and Amazon App for Zigbee technology
  • Compatible with Alexa, Google Home and IFTTT, using the dedicated gateway or Zigbee hub
  • Compatible with SmartThings hub

产品状态
3 - Active

您可能也感兴趣

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
230 V
Rated current
2,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Blue
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
46,40 mm

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

92. RoHS UAE

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352628564
1 NR
6x5.4x5.2 [cm]
45.6 [g]
Barcode Qty 60 NR
8007352628571
60 NR
37.5x30x13.5 [cm]
2,920 [g]
问题: After I have set the device as Zigbee, how can I reset the device to Bluetooth mode?
回答: The procedure allowing the conversion of the operating mode/technology on the product in question can be found inside the ˝VIEW Wireless˝ App in the menu: ˝Actions -> Manage device˝.
问题: Can the product in question be used for roller shutters without adjustable slats?
回答: The product in question, if used in BLE (Bluetooth Low Energy) mode and configured using the VIEW Wireless App, envisages on this application the possibility of setting the device to operate as ˝roller shutter without slats˝.
