Classic plate 5M BS technopolymer white - 19649.74

Pdf
Vimar - 19649.74 - Classic plate 5M BS technopolymer white
Vimar - 19649.74 - Classic plate 5M BS technopolymer white

19649.74
Wiring devices / Traditional wiring devices / ARKÉ / Cover plates

Classic plate 5M BS technopolymer white
5-module Classic cover plate, British standard, technopolymer, white

产品状态
3 - Active

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
5
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
1
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
1
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
155,00 mm
Height
90,00 mm
Depth
8,60 mm
Built-in width
155,00 mm
Built-in height
90,00 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

08. ASTA - UK

29. QCERT - Colombia

43. UKCA mark - Great Britain

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352602717
1 NR
15.5x9x0.86 [cm]
23 [g]
Barcode Qty 10 NR
8007352603219
10 NR
17.7x9.8x10.3 [cm]
291 [g]
