2P 16AX 1-way switch grey - 20015

Pdf

20015
Wiring devices / Traditional wiring devices / EIKON / Devices

2P 16AX 1-way switch grey
2P 16 AX 250 V~ 1-way switch, lightable, replaceable button, grey. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Device width
22,30 mm
Device height
49,00 mm
Device depth
36,80 mm
Built-in depth
25,00 mm

00. CE Marking - EU

13. SNI - Indonesia

19. NOM - Mexico

20. IQC - Argentina

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352250949
1 NR
4.1x2.8x5.3 [cm]
31.6 [g]
Barcode Qty 50 NR
8007352250956
50 NR
21.4x11.6x14.2 [cm]
1,669.53 [g]
Barcode Qty 500 NR
8007352641181
500 NR
57.5x22.5x30 [cm]
17,215 [g]
Barcode Qty 10,500 NR
8007352750777
10,500 NR
120x80x105 [cm]
361,515 [g]
