TV-RD-SAT single-conn.out.2outs Next - 20302.01.N

Pdf
20302.01.N

Eikon Next / Devices / 2-outlet TV/RD/SAT socket outlets

TV-RD-SAT single-conn.out.2outs Next
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, single connection, demix, 2 outputs with male (TV-RD) and female F-type (SAT) connectors, connection attenuation 1 dB, Next - 2 modules. Allows the passage of d.c. current and control signals (24 V 500 mA max) through the female connector

产品状态
3 - Active

Class group
Antenna and satellite technique
Class
Antenna socket box
Model
TWIN end socket
Cover
None
Tap loss at 860 MHz
1,00 dB
Tap loss at 2150 MHz
1,00 dB
Number of outlets
2
Suitable for remote power supply
Yes
Frequency
5 - 2400 MHz
Type of fastening
Snap mounting (engagement)
Colour
Silver
RAL-number (similar)
9022
Material
Plastic

00. CE Marking - EU

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

92. RoHS UAE

最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352403062
1 NR
5.1x4.3x5.3 [cm]
79 [g]
Barcode Qty 5 NR
8007352403079
5 NR
14.4x11.6x6 [cm]
447.8 [g]
