Vertical badge switch 2M white - 20463.B

Pdf
Vimar - 20463.B - Vertical badge switch 2M white
Vimar - 20463.B - Vertical badge switch 2M white

20463.B
Wiring devices / Traditional wiring devices / EIKON / Devices

Vertical badge switch 2M white
Upright electronic badge switch, 4 A 250 V~ NO (NON SELV) change-over relay output, power supply 120-230 V~ 50-60 Hz, slot lighting for location in the dark, trimmer for regulating switch-off time after removing the card, white - 2 modules. Supplied without ISO card (badge)

产品状态
3 - Active

单, 说明书, 文档

图纸

PNG DXF
PNG DXF
Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
None
Reading strategy
Data medium
Signalling
None
Mounting method
Flush-mounted
Operating voltage AC 50 Hz
250,00 - 250,01 V
Operating voltage AC 60 Hz
250,00 - 250,01 V
Operating temperature
5 - 35 °C
Degree of protection (IP)
IP20
Colour
White
Material
Plastic
Width
44,80 mm
Height
49,00 mm
Depth
43,50 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352561410
1 NR
5.2x5.7x7.6 [cm]
69.3 [g]
Barcode Qty 5 NR
8007352563797
5 NR
21.4x11.6x6 [cm]
404.8 [g]
Barcode Qty 50 NR
8007352727595
50 NR
30.5x25.5x22.5 [cm]
4,048 [g]
