Speaker 8ohm 3W 3M Next - 20587.N

Pdf

20587.N
Smart systems&products / By-me Plus / Shared components / Devices

Speaker 8ohm 3W 3M Next
Passive speaker 8 ohm 3 W RMS, to complete with Eikon, Arké or Plana cover plates, Next - 3 modules

产品状态
3 - Active

Class group
Consumer electronics
Class
Loudspeaker box
Colour
Silver
Suitable for ceiling mounting
No
Suitable for built-in mounting
Yes
Suitable for wall mounting
Yes
Horn speaker
No
Sound projector
No
Frequency
120 - 20.000 HZ
Impedance
8,00 - 8,01 Ohm
Nominal capacity
3 W
Active system
No
Bass reflex system
Yes
Loudness control
No
Degree of protection (IP)
IP40
Width
67,30 mm
Height
4.900,00 mm
Depth
50,00 mm

00. CE Marking - EU

19. NOM - Mexico

43. UKCA mark - Great Britain

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352400757
1 NR
11.2x9.6x9.8 [cm]
152.78 [g]
问题: Can I use a 10+10 W amplifier with 3W speakers?
回答: Yes, it is possible to combine amplifier 01901 to speakers 20587.
问题: What is the maximum distance between the amplifier 14581, 20581 and the speakers 20587?
回答: The maximum distance between the speaker and amplifier depends on the cable section used. With a 1.5 mm cable, the distance can be up to 30 m, while the maximum distance drops to 10 m for a 1 mm cable.
