22673.3.01
Wiring devices / Traditional wiring devices / EIKON / Cover plates
Plate 3Mx3 Vintage matt white
Plate 3Mx3 Vintage matt white
产品状态
3 - Active
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Cover frame for domestic switching devices
Cover frame for domestic switching devices
Number of units
3
3
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of units horizontal
3
3
Number of units vertical
1
1
Number of modules horizontal (module system)
3
3
Number of modules vertical (module system)
1
1
With mounting grid
Yes
Yes
Suitable for subfloor installation duct box
Yes
Yes
Suitable for wall duct
Yes
Yes
Suitable for built-in installation
Yes
Yes
Label space/information surface
Yes
Yes
Material
Metal
Metal
Material quality
Other
Other
Surface protection
Lacquered
Lacquered
Surface finishing
Matt
Matt
Colour
White
White
RAL-number (similar)
9003
9003
Transparent
No
No
With hinged lid
No
No
Degree of protection (IP)
IP00
IP00
Type of fastening
Clamp mounting
Clamp mounting
Width
122,00 mm
122,00 mm
Height
90,00 mm
90,00 mm
Depth
7,15 mm
7,15 mm
Built-in width
122,00 mm
122,00 mm
Built-in height
90,00 mm
90,00 mm
Diameter bore hole (opening)
0,00 mm
0,00 mm
最小订单数量: 1 NR
条形码
8007352621640
1 NR
12.5x9.5x1.4 [cm]
213.4 [g]
8007352621657
5 NR
13.5x8x10.4 [cm]
1,114.8 [g]
