22751.0.12

Eikon EXÉ / Accessories / Vintage and Flat devices

2 buttons Flat w/o symbol bronze
2 buttons Flat w/o symbol bronze

产品状态
3 - Active

PNG DXF

Class group
Domestic switching devices

Class
Push-switch button

Assembly arrangement
Other

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
1

Number of poles
2

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush mounted (plaster)

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
Bronze

RAL-number (similar)
7010

Transparent
No

Label space/information surface
Yes

Height of device
15,00 mm

Depth of device
8,25 mm

01. IMQ - Italy

最小订单数量: 1 NR

8007352621046

1 NR

3.5x6.5x1.5 [cm]

2.8 [g]

8007352621053

20 NR

14.5x11x7.5 [cm]

86.6 [g]

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
