2 buttons Flat arrows symbol bronze - 22751.2.12

Pdf

22751.2.12
Wiring devices / Traditional wiring devices / EIKON / Buttons

2 buttons Flat arrows symbol bronze
2 buttons Flat arrows symbol bronze

产品状态
3 - Active

图纸

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Other
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
2
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Bronze
RAL-number (similar)
7010
Transparent
No
Label space/information surface
Yes
Device height
15,00 mm
Device depth
8,25 mm
最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352621244
1 NR
3.5x6.5x1.5 [cm]
2.6 [g]
Barcode Qty 20 NR
8007352621251
20 NR
14.5x11x7.5 [cm]
86.4 [g]
