30135.B
Wiring devices / Traditional wiring devices / LINEA / Devices
Stand alone universal dimmer 230V white
Universal 230 V~ 50 Hz phase cutting dimmer, for 40-400 W incandescent lamps, 40-300 VA electronic transformers, 10-200 W CFL lamps, 3-200 W LED lamps, for LED phase cutting electronic power supply units, ON/OFF control and adjustment with built-in push buttons or via NO peripheral push buttons, minimum brightness control, visible in darkness, white
产品状态
3 - Active
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Dimmer
Dimmer
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Method of operation
Push button
Push button
Number of modules (module system)
1
1
App control via Bluetooth
No
No
Dimming phase cut-on (leading edge)
Yes
Yes
Dimming phase cut-off (trailing edge)
Yes
Yes
Serial dimmer
Yes
Yes
Type of load
Universal and LED Retrofit
Universal and LED Retrofit
Substation input
Yes
Yes
Light value memory
Yes
Yes
Applicable with button
Yes
Yes
Applicable with movement sensor
No
No
Applicable with presence indicator
No
No
Applicable with time switch/timer
No
No
Applicable with transmission button
No
No
Applicable with infrared button
No
No
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Snapper mounting
Snapper mounting
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
White
White
RAL-number (similar)
9016
9016
Transparent
No
No
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
230,00 - 230,01 V
230,00 - 230,01 V
Frequency
50,00 - 50,01 HZ
50,00 - 50,01 HZ
Control voltage
230,00 - 230,01 V
230,00 - 230,01 V
Nominal power resistive load
40 - 400 W
40 - 400 W
Nominal power inductive load
40 - 300 VA
40 - 300 VA
Nominal power capacitive load
40 - 300 VA
40 - 300 VA
Max. switching power LED
200 W
200 W
Connection type
Screwed terminal
Screwed terminal
Core cross section
0,00 - 250,00
0,00 - 250,00
Device width
22,20 mm
22,20 mm
Device height
52,70 mm
52,70 mm
Device depth
48,70 mm
48,70 mm
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
最小订单数量: 1 NR
条形码
8007352713666
1 NR
6x4.5x5.4 [cm]
48.78 [g]
8007352713673
10 NR
23.5x12.5x6.5 [cm]
487.8 [g]
