IoT connected 2-way switch mechanism - 30802

Pdf

Vimar - 30802 - IoT connected 2-way switch mechanism

30802
Wiring devices / View Wireless wiring devices / LINEA / Devices

IoT connected 2-way switch mechanism
VIEW Wireless electronic switch mechanism with 100-240 V~ relay output for 500 W incandescent lamps, 100W LED lamps, 250 VA electronic transformers, 120 W fluorescent lamps, local or remote control, double IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system and on Zigbee 3.0 standard, 1 input for external push button for actuator control or to recall a scenario, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, to be completed with Linea 1-module interchangeable buttons

产品状态
3 - Active

您可能也感兴趣

31000.B - Button 1M aligned white

31000A.B - Axial button 1M white

31000S.B - White lower 1M path light button

31000.C - Button 1M aligned Canvas

31000A.C - Axial button 1M canvas

31000S.C - Lower 1M path light button Canvas

31000.G - Button 1M aligned 1M black

31000A.G - Axial button 1M black

31000S.G - Black lower 1M path light button

30807.G - IoT connected Gateway 2M black

30807.B - IoT connected Gateway 2M white

30807.C - IoT connected Gateway 2M canvas

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Anti-bacterial treatment
No

Surface protection
Untreated

Surface finishing
Matt

Colour
Black

RAL-number (similar)
7024

Label space/information surface
No

Illumination
Yes

Function lighting
Control and orientation

Type of lighting
LED not exchangeable

Suitable for degree of protection (IP)
IP40

Impact strength
Other

Nominal voltage
240 V

Feedback-signal contact
No

Connection type
Screwed terminal

Heating switch
No

Washing machine switch
No

Device width
22,30 mm

Device height
52,80 mm

Device depth
44,70 mm

Built-in depth
39,00 mm

Compatible with Apple HomeKit
Yes

Compatible with Google Assistant
Yes

Compatible with Amazon Alexa
Yes

IFTTT support available
Yes

00. CE Marking - EU

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352689596

1 NR

6x4.5x5.4 [cm]

47.33 [g]

8007352751835

60 NR

27x23x12.5 [cm]

3,129.96 [g]

8007352689602

72 NR

37.5x30x13.5 [cm]

3,756 [g]
