Axial button 2M light symbol black - 31000A.2LG

Pdf
Vimar - 31000A.2LG - Axial button 2M light symbol black
Vimar - 31000A.2LG - Axial button 2M light symbol black

31000A.2LG
Wiring devices / Traditional wiring devices / LINEA / Buttons

Axial button 2M light symbol black
2-module interchangeable button for axial controls, lightable light symbol, black

产品状态
3 - Active

您可能也感兴趣

30000.2
30000.2 - Axial 1P 10AX 1-way switch mechanism 2M
30004.2
30004.2 - 1P 10AX 2M axial 2-way switch mechanism
30008.2
30008.2 - 1P NO 10A 2M axial button mechanism
30012.2
30012.2 - 1P 10AX 2M axial reversing switch mech.

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
One-part button
Imprint/indication
Symbol ˝light˝
Scannable symbol/barrier free
No
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Anti-bacterial treatment
No
Colour
Black
RAL-number (similar)
7021
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Width
4.460,00 mm
Height
5.270,00 mm
Depth
530,00 mm

00. CE Marking - EU

01. IMQ - Italy

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352697287
1 NR
10x7.5x0.8 [cm]
7.12 [g]
Barcode Qty 10 NR
8007352697294
10 NR
11.2x9.2x9.8 [cm]
136.2 [g]
