EKKO 400D linear operator 24V 4m 250kg - EAM3

Pdf
Vimar - EAM3 - EKKO 400D linear operator 24V 4m 250kg
Vimar - EAM3 - EKKO 400D linear operator 24V 4m 250kg

EAM3
Safety / ELVOX Automations / Motors / Hinged

EKKO 400D linear operator 24V 4m 250kg
EKKO 400D non-reversible 24 V electromechanical linear operator for swing gates up to 4 m and 250 kg, complete with fixing brackets and motor with magnetic encoder

产品状态
3 - Active

Class group
Gate operators, pumps and ventilators
Class
Swing gate operator
Model
One-wing, left and right
Max. width of door/gate wing
4.000 mm
Max. weight of door/gate leaf
550 kg
Type of current
DC
Motor voltage
24 V
Limit switch
Internal end switch
With motor control unit
No
With post fittings
Yes
With wing fittings
Yes
With key-switch
No
With radio receiver
No

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406228147
1 NR
103x16x17.2 [cm]
10,200 [g]
