Flush junction box 515x292x80mm - V70011

Pdf
V70011

Enclosures and mounting boxes / Junction flush mounting boxes / Mounting boxes

Flush junction box 515x292x80mm
Flush mounting junction box with white cover and fixing screws. Supplied with 5 dividing screens. Dimensions 515x292x80 mm

产品状态
3 - Active

您可能也感兴趣

Class group
Connection devices
Class
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush mounted (plaster)
Shape
Rectangular
Construction type
Device connection box (round/square)
Model
Other
Provided with revolving ring
No
Can be coupled
Yes
Equipped with
None
Diameter
0 mm
Length
515,00 mm
Width
515,00 mm
Depth
0,00 - 80,00 mm
Internal depth
80,00 mm
For number of electric fittings
0
Mounting switching equipment
Spread
With screws
No
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
For tube diameter
Other
Pipe locking
No
Pipe locking optional
No
Inlet from the rear
Yes
Number of inlets
48
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP00
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Sealable
No
Circuit integrity
None
With screening
No
Wind proof
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
With nail lugs
No
Special application
None
最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352082090
1 NR
53.4x31.2x8.6 [cm]
1,374.13 [g]
Barcode Qty 5 NR
8007352115675
5 NR
59x39x44 [cm]
7,858.67 [g]
Barcode Qty 80 NR
8007352352520
80 NR
80x120x190 [cm]
133,000 [g]
