Steckdose 2P+E 10A P11 weiß - 09201

Pdf
09201

Neve Up / Geräte / Steckdosen - italienische Standards

Steckdose 2P+E 10A P11 weiß
SICURY-Steckdose 2P+E 10 A 250 V~ italienischer Standard P11, weiß

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Steckdose
Model
Italian type P11
With built-in USB power supply
No
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
10 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
22,30 mm
Height of device
47,00 mm
Depth of device
32,70 mm

00. CE-Kennzeichnung - EU

07. INGCER - Chile

10. EAC Eurasian Customs Union

19. NOM - Mexiko

37. Kennzeichnung - Marokko

Mindestbestellmenge: 50 NR

Barcode

Barcode Qty 1 NR
8007352296176
1 NR
4,1x2,8x5,3 [cm]
26,27 [g]
Barcode Qty 50 NR
8007352296183
50 NR
21,4x11,6x14,2 [cm]
1.415,6 [g]
Barcode Qty 500 NR
8007352296190
500 NR
57,5x22,5x30 [cm]
14.682,67 [g]

Teilen

Codice QR scheda articolo

Legal

Vimar behält sich das Recht vor, jederzeit und ohne Vorankündigung die Merkmale der gemeldeten Produkte zu ändern. Die Installation muss durch Fachpersonal gemäß den im Anwendungsland des Geräts geltenden Vorschriften zur Installation elektrischen Materials erfolgen. Für die Nutzungsbedingungen der im Produktblatt enthaltenen Informationen verweisen wir auf Nutzungsbedingungen.
