Vier Halbwippen 1M Pfeil-Symbol Next - R20841.3.N

Pdf
R20841.3.N

Eikon Next / Ersatzteile / KNX

Vier Halbwippen 1M Pfeil-Symbol Next
Ersatzteil für vier austauschbare 1- Modul-Halbtasten, Symbol Richtungspfeil, Next

Produktstatus
3 - Aktif

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Abdeckung/Bedienelement für Installation
Model
Other
Imprint/indication
Symbol ˝arrows˝
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Depth
570 mm
Mindestbestellmenge: 1 NR

Barcode

Barcode Qty 1 NR
8007352619364
1 NR
4,4x2,2x1,2 [cm]
5,93 [g]
Barcode Qty 6 NR
8007352619371
6 NR
14,2x6,7x5,9 [cm]
66,55 [g]
