Κουτί διανομής γυψοσανί 298x164x73,5mm - V72007

Pdf

V72007
Υποδομή εγκατάστασης / Κουτιά και πίνακες / Κουτιά διακλάδωσης / Χωνευτά

Κουτί διανομής γυψοσανί 298x164x73,5mm
Χωνευτό κουτί διακλάδωσης για κοίλους τοίχους με λευκό κάλυμμα και βίδες στερέωσης.Διαστάσεις 298x164x73.5 mm

Κατάσταση Προϊόντος
3 - Προϊόν διαχειριζόμεν

Σχέδια

Class group
Connection material (electrotechnical)
Class
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush-mounted
Shape
Rectangular
Construction type
Cable junction box
Model
Other
Provided with revolving ring
No
Couplable
Yes
Equipped with
None
Diameter
0 mm
Length
298,00 mm
Width
298,00 mm
Depth
0,00 - 73,50 mm
Inner depth
73,50 mm
For number of electric fittings
0
Mounting switching equipment
Spread
With screws
Yes
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
For tube diameter
Other
Pipe locking
Yes
Pipe locking optional
Yes
Inlet from the rear
Yes
Number of inlets
18
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP20
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Sealable
No
With screening
No
Air tight
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
Special application
None

00. Σήμανση CE - ΕE

43. UKCA - Μεγάλη Βρετανία

50. Product Environm. Profile

Ελάχιστη ποσότητα παραγγελίας: 7 NR

Γραμμωτός κώδικας

Barcode Qty 1 NR
8007352589940
1 NR
32,3x22,7x7,6 [cm]
496 [g]
Barcode Qty 7 NR
8007352589957
7 NR
59x38,5x24 [cm]
4.188 [g]
