Interruptor 2P 32A blanco - 09020

Pdf
09020

Neve Up / Dispositivos / Dispositivos de mando básicos

Interruptor 2P 32A blanco

Estado producto
3 - Activo

Dibujos

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Illumination
Yes
Function lighting
Other
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
32,00 A
Switching current for fluorescent lamps
0
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
Yes
Washing machine switch
Yes
Width of device
44,80 mm
Height of device
47,00 mm
Depth of device
0,00 mm
Built-in depth
30,50 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Min. depth of built-in installation box
35 mm
Compatible with Amazon Alexa
No
IFTTT support available
No

00. Marcado CE - UE

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 10 NR

Código de barras

Barcode Qty 1 NR
8007352703230
1 NR
5,1x4,3x5,3 [cm]
50,4 [g]
Barcode Qty 10 NR
8007352703247
10 NR
26,9x11,6x4,9 [cm]
577 [g]
Barcode Qty 200 NR
8007352703254
200 NR
47,5x27x29 [cm]
12.240 [g]
