Idea / Placas / Placas Classica metal
Placa Classica 3M met.oro mate
Placa Classica 3 módulos, aleación de metal, oro mate
Estado producto
3 - Activo
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
3
Mounting direction
Horizontal and vertical
Number of units horizontal
3
Number of units vertical
1
Number of modules horizontal (module system)
3
Number of modules vertical (module system)
1
Number of switch inserts
0
With mounting grid
Yes
Suitable for floor box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Gold
RAL-number (similar)
1036
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
120,00 mm
Height
82,00 mm
Depth
9,25 mm
Built-in width
120,00 mm
Built-in height
82,00 mm
Diameter bore hole (opening)
0 mm
Cant. mínima de pedido: 1 NR
Código de barras
8007352102958
1 NR
12,5x8,5x1,1 [cm]
101,45 [g]
8007352102965
10 NR
13,5x12,4x9,2 [cm]
1.166,3 [g]
8007352703827
160 NR
50,5x20x28 [cm]
19.100 [g]
