19000.B
Arké blanca / Dispositivos / Dispositivos de mando básicos
Interruptor 1P 10AX blanco
Interruptor 1P 10 AX 250 V~, iluminable, tecla intercambiable, blanco. Máx 100 W para lámparas con alimentador integrado (IEC 60669-1:2017)
Estado producto
4 - Activo
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
1.000 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
10. EAC Eurasian Customs Union
43. Marca UKCA - Gran Bretaña
Cant. mínima de pedido: 50 NR
Código de barras
8007352684768
1 NR
4,1x2,8x5,3 [cm]
24,6 [g]
8007352684775
50 NR
21,4x11,6x14,2 [cm]
1.314,8 [g]
8007352684782
500 NR
57,5x22,5x30 [cm]
14.300 [g]
8007352704909
10.500 NR
80x120x103 [cm]
300.300 [g]
Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
