Supply unit 230V~ 29Vdc 400mA - 01400

Pdf
Vimar - 01400 - Supply unit 230V~ 29Vdc 400mA
Foto gallery #1
Foto gallery #2
Vimar - 01400 - Supply unit 230V~ 29Vdc 400mA

01400
Smart systems&products / By-me Plus / Shared components / DIN devices

Supply unit 230V~ 29Vdc 400mA
Power supply with 29 Vdc 400 mA output, supply voltage 230 V~ 50/60 Hz, with decoupling coil (choke) for DIN (60715 TH35) rail installation, occupies 2 17,5 mm modules

产品状态
3 - Active

Class group
Installation bus systems
Class
Power supply for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Mounting method
Other
Width in number of modular spacings
2
With LED indication
No
Bus voltage stockable
No
Number of integrated choke coils
1
Number of lines to feed
2
Max. output current
400,00 mA

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352511873
1 NR
14.2x6.7x5.9 [cm]
167 [g]
Barcode Qty 40 NR
8007352573130
40 NR
36.5x28x24.5 [cm]
7,010 [g]
问题： Is a BUS connection necessary to control 6 loads via articles 01455 and 01471?
回答： The products indicated not only necessarily have to be connected to one another via BUS cable, but a system home automation system power supply unit must also be envisaged (e.g. 01400 or 01401 according to need) and they must be commissioned via the related configurator device.
