By-me/DALI-2 gateway 64-channel/16groups - 01419.1

Pdf
Vimar - 01419.1 - By-me/DALI-2 gateway 64-channel/16groups
Vimar - 01419.1 - By-me/DALI-2 gateway 64-channel/16groups

01419.1
Smart systems&products / By-me Plus / Shared components / DIN devices

By-me/DALI-2 gateway 64-channel/16groups
Actuator for DALI/DALI-2 lamps with integrated power supply unit, MASTER controller function, max. 64 lamps configurable in 16 By-me Functional Blocks via View PRO App, DALI Device Type 8 for tunable white and RGB(W) management, By-me home automation system, push button for local control, 120-240 V~ 50/60 Hz power supply, installation on DIN rail (60715 TH35), occupies 2 modules size 17.5 mm

产品状态
3 - Active

Class group
Installation bus systems
Class
System interface/media gateway for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Light system interface/DALI
Mounting method
DRA (DIN-rail adapter)
Width in number of modular spacings
4
Demounting protection
No
With LED indication
Yes
Updateable
Yes
Protocol
Other
Provider dependent
No
Visualization
No
Web-Server
No
Radio interface
No
IR interface
No
Degree of protection (IP)
IP20

00. CE Marking - EU

43. UKCA mark - Great Britain

92. RoHS UAE

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352657571
1 NR
14.2x6.2x5.6 [cm]
143.6 [g]
