01450

Surface mounting equipments / Systems / Energy components

Energy meter 3IN toroidal sensor
Energy meter, 3 inputs for toroidal current sensor, measurable powers 25 W-100 kW, single phase power supply 120-230 V 50/60 Hz three phase 230/400 V 50/60 Hz, installation on DIN rail (60715 TH35), occupies 1 x 17.5 mm module. Supplied with toroidal current sensor.

产品状态
4 - Active

单, 说明书, 文档

视频

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Sensor control for bus system

Bus system KNX
No

Bus system KNX radio
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
Other

Model
Other

Mounting method
Other

Number of inputs
3

Degree of protection (IP)
IP20

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352498914

1 NR

14.2x6.7x5.9 [cm]

119.8 [g]

问题：	If I wish to monitor the consumption values of some household appliances do I always need the load control module 01455?
回答：	No. If you only need to measure the consumption of one or more loads, all that is required are articles which support the ˝current sensor˝ function, such as 01450, 01456, 01451 and flush mounting actuators 14537. To view and save the data, you will need a touchscreen and/or webserver type supervision device
问题：	Article 01455 is used to manage both the consumption and production of the energy system or is it also necessary to install article 01450?
回答：	Article 01455 is designed for the inlet of three current sensors. This means that in a single phase system in which the production meter is at a maximum distance of 40 cm from the consumption meter, it is possible to use only art.01455 with two current sensors. In three-phase systems or single phase systems with a production meter located in another room or at a distance of more than 40 cm, in addition to the load control module art.01455, you will also need meter art.01450.
