Zigbee Friends of Hue RF switch - 03906

Pdf

03906
Smart systems&products / Smart switch&sound / Surface mounting components / Non-modular components

Zigbee Friends of Hue RF switch
4-button flat switch with 2.4 GHz Zigbee Green Power and Friends of Hue standard radiofrequency transmitter, energy harvesting supply powered by built-in electrodynamic generator, to complete with Eikon 20506, Arké 19506 or Plana 14506 buttons - 2 modules

  • Batteries are not required: the power supply is self-generated on pressing the push button, which activates the internal electro-dynamic generator. This small fraction of energy is capable of activating the radio frequency wave
  • The wireless 1-way switch designed to be positioned anywhere, including on glass or wood, requires no masonry work
  • Since they do not require wired connections, the signal is transmitted via radio
  • Use of low energy radio technologies applied to the controls, electromagnetic radiation and pollution are practically non-existent
  • Batteries are not required, thus respecting the environment

产品状态
3 - Active

您可能也感兴趣

Class group
Installation bus systems
Class
Light control unit for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
No
Mounting method
Surface mounted
Width in number of modular spacings
2
With bus connection
No
Substation input
No
Local operation/hand operation
No
With LED indication
No
Interface 1-10 V
No
Number of inputs for light sensor
0
Degree of protection (IP)
IP40

10. EAC Eurasian Customs Union

32. FCC - USA

33. ISED - Canada

37. Marking - Morocco

42. Zigbee certified

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352596030
1 NR
5.1x4.3x5.3 [cm]
38.3 [g]
Barcode Qty 6 NR
8007352596047
6 NR
14.4x11.6x6 [cm]
275.6 [g]
