Button 1M flame symbol carbon matt - 09021.H.CM

Pdf
Vimar - 09021.H.CM - Button 1M flame symbol carbon matt
Vimar - 09021.H.CM - Button 1M flame symbol carbon matt

09021.H.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Button 1M flame symbol carbon matt
1-module interchangeable button, lighTable flame symbol, carbon matt

产品状态
3 - Active

您可能也感兴趣

09021.H.CM
09021.H.CM - Button 1M flame symbol carbon matt
09005.0.250
09005.0.250 - 1P 16AX 2-way switch mechan.+pilot250V
09008.0.250
09008.0.250 - 1P NO 10A push button mechan.+pilot 250V
09008.0.12
09008.0.12 - 1P NO 10A push button mechan.+pilot 12V

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
One-part rocker
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Anthracite
RAL-number (similar)
7016
With exchangeable lens/symbol
Yes
Depth
750,00 mm

00. CE Marking - EU

29. QCERT - Colombia

29. QCERT - Colombia

43. UKCA mark - Great Britain

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352659339
1 NR
2.2x4.4x1.1 [cm]
6.326 [g]
Barcode Qty 5 NR
8007352659346
5 NR
5.1x2.8x5.3 [cm]
24.06 [g]
Barcode Qty 50 NR
8007352659353
50 NR
14.4x11.6x6 [cm]
281.3 [g]
Barcode Qty 600 NR
8007352668737
600 NR
36.5x33x13.5 [cm]
3,795.6 [g]
