2P 10AX switch carbon matt - 09060.CM

Pdf

09060.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P 10AX switch carbon matt
2P 10 AX 250 V~ switch (6 terminals), with two buttons, with direction arrows and central OFF position, carbon matt. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Other
Number of rockers
1
Number of modules (module system)
100
Number of poles
2
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No
Label space/information surface
Yes
Device width
22,30 mm
Device height
47,00 mm
Device depth
44,60 mm

00. CE Marking - EU

13. SNI - Indonesia

19. NOM - Mexico

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352665798
1 NR
5.1x2.8x5.3 [cm]
41.4 [g]
Barcode Qty 10 NR
8007352665804
10 NR
14.4x11.6x6 [cm]
456.4 [g]
Barcode Qty 120 NR
8007352665811
120 NR
37.5x30x13.5 [cm]
5,818 [g]
