Vimar - 09062.CM - Two interlocked 1P NO+NO 10A pushes carb

09062.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Two interlocked 1P NO+NO 10A pushes carb
Two interlocked 1P NO + 1P NO 10 A 250 V~ buttons, with directional arrows, carbon matt

产品状态
3 - Active

您可能也感兴趣

09060.CM - 2P 10AX switch carbon matt

图纸

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Anti-bacterial treatment
No

Surface protection
Untreated

Surface finishing
Glossy

Colour
Anthracite

RAL-number (similar)
7016

Transparent
No

Label space/information surface
Yes

Device width
22,30 mm

Device height
47,00 mm

Device depth
38,50 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

29. QCERT - Colombia

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352665828

1 NR

4.1x2.8x5.3 [cm]

32 [g]

8007352665835

20 NR

21.4x11.6x6 [cm]

694.2 [g]

8007352665842

200 NR

30.5x25.5x22.5 [cm]

7,284 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
