TV-RD-SAT single conn.male outlet white - 09300.01

Pdf
Vimar - 09300.01 - TV-RD-SAT single conn.male outlet white
Vimar - 09300.01 - TV-RD-SAT single conn.male outlet white

09300.01
Wiring devices / Traditional wiring devices / NEVE UP / Devices

TV-RD-SAT single conn.male outlet white
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, single connection, with male connector, connection attenuation 1 dB, white. Allows the passage of d.c. current and control signals (24 V 500 mA max)

产品状态
3 - Active

您可能也感兴趣

09300.10
09300.10 - TV-RD-SAT through-line male outlet white
09303
09303 - TV-FM-SAT single conn. 3outs white
09318
09318 - F-type TV outlet white
09313
09313 - TV IEC single connection outlet white
09302.01
09302.01 - TV-RD-SAT single conn.outlet 2outs white

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Antenna and satellite technique
Class
Antenna socket box
Model
End socket
Cover
None
Tap loss at 860 MHz
0,10 dB
Tap loss at 2150 MHz
0,20 dB
Number of outlets
1
Suitable for remote power supply
Yes
Type of fastening
Snap mounting (engagement)
Colour
White
RAL-number (similar)
9003
Surface finishing
Glossy
Material
Plastic

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352296381
1 NR
4.1x2.8x5.3 [cm]
39.8 [g]
Barcode Qty 10 NR
8007352296398
10 NR
14.4x9x6 [cm]
434.2 [g]
Barcode Qty 160 NR
8007352296404
160 NR
37.5x30x13.5 [cm]
7,270 [g]
