Vimar - 09967.1 - 2P+E 16A universal outlet for DIN rail

09967.1
System infrastructure / Enclosures and control units / Switchboards / Shared accessories

2P+E 16A universal outlet for DIN rail
2P+T 16 A 250 V~ universal SICURY socket outlet, Italian standard P40, for installation on DIN rail (60715 TH35), occupies 3 modules size 17.5 mm, depth 56 mm, RAL 7035 grey

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Socket outlet

Model
Other

Number of units
1

Number of modules (module system)
2

Number of socket outlets switchable
0

Imprint/indication
None

Connection type
Screwed terminal

With hinged lid
No

With enhanced contact protection
Yes

Label space/information surface
Yes

Colour
White

RAL-number (similar)
9001

Metallic colour
No

Transparent
No

Lockable
No

Eject-mechanism
No

Insulated mounting
No

With function lighting
No

Over voltage protection
No

Fault current protection
No

Mounting method
Flush-mounted

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

With loop through function
No

With on/off switch
No

Rotated central insert
No

Nominal current
16 A

Nominal voltage
250 V

Frequency
50,00 - 60,00 HZ

Suitable for degree of protection (IP)
IP20

Impact strength
Other

Device height
45,00 mm

Device depth
53,00 mm

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352621565

1 NR

5.2x7x6 [cm]

70.556 [g]

8007352621572

20 NR

29.8x26.2x6.5 [cm]

1,630.92 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
