Surface-box 1-2M 43,5mm depth white - 09971.01

Pdf

Vimar - 09971.01 - Surface-box 1-2M 43,5mm depth white

09971.01
System infrastructure / Enclosures and control units / Connector block boxes / Surface mounting

Surface-box 1-2M 43,5mm depth white
Square surface mounting box, 43,5 mm depth, for 1- or 2-reduced-module Idea and 2-module Eikon and Plana with relevants mounting frames and cover plates, white. Idea series: suitable for Classica cover plate only

产品状态
3 - Active

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Connection material (electrotechnical)

Class
Box/housing for surface mounting on the wall/ceiling

Max. conductor cross section
0

Equipped with
None

Shape
Rectangular

Mounting method
Wall-/ceiling mounting

Mounting in the soil
No

Mounting under water
No

For tube diameter
20/25 mm

Inlet from the rear
No

Length
84,00 mm

Width
84,00 mm

Depth
43,50 mm

Diameter
0 mm

Tackable
No

Number of inlets
2

Type of housing feed-through
None

Material
Plastic

Halogen free
Yes

Surface protection
Untreated

Colour
White

Degree of protection (IP)
IP20

Cover model
Other

Transparent cover
No

Cover attachment
Screwed

Castable
No

With casting compound
No

Sealable
No

Rated insulation voltage Ui
450 V

Circuit integrity
None

With screening
No

Weatherproof
No

Operating temperature
0 - 60 °C

Explosion-tested version
No

For Ex-zone gas
None

For Ex-Zone dust
None

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

最小订单数量: 20 NR

条形码

8007352130234

1 NR

9.2x8.4x4.5 [cm]

72.4 [g]

8007352130241

20 NR

28.4x24.4x14.9 [cm]

1,658.07 [g]
