09973.A
System infrastructure / Enclosures and control units / Connector block boxes / Surface mounting
Surface-box 3M 40mm depth ivory
3-module surface mounting box, 40 mm depth, for 8000, Linea and 7000 with relevants mounting frame, cover plates or self-bearing cover plates, RAL 9001 ivory. Not suitable for 08065..., 08081..., 08341, 08342, 08440, 08441, 08443, 08445, 08446, 08450, 08470, 08480, 08481, 10064..., 10065..., 10081.... To be installed on insulating non-perforated or metallic with earth connection surfaces.
产品状态
3 - Active
图纸
Class group
Electrical installation, isolation and connection material
Electrical installation, isolation and connection material
Class
Box/housing for surface mounting on the wall/ceiling
Box/housing for surface mounting on the wall/ceiling
Model
Mounting box
Mounting box
Equipped with
None
None
Max. conductor cross section
0,00 mm2
0,00 mm2
Shape
Rectangular
Rectangular
Mounting method
Wall-/ceiling mounting
Wall-/ceiling mounting
Mounting in the soil
No
No
Mounting under water
No
No
For tube diameter
20/25 mm
20/25 mm
Number of inlets
4
4
Length
80,00 mm
80,00 mm
Width
124,00 mm
124,00 mm
Depth
40,00 mm
40,00 mm
Diameter
0,00 mm
0,00 mm
Connectable
No
No
Material
Plastic
Plastic
Surface protection
Untreated
Untreated
Colour
Other
Other
Transparent cover
No
No
Castable
No
No
Cover attachment
Screwed
Screwed
Casting compound included
No
No
Sealable
No
No
Rated insulation voltage Ui
450 V
450 V
Circuit integrity
None
None
With screening
No
No
Working temperature
0 - 60 °C
0 - 60 °C
Explosion-tested version
No
No
For Ex-zone gas
None
None
For Ex-zone dust
None
None
最小订单数量: 20 NR
条形码
8007352043855
1 NR
12x8x4 [cm]
53.27 [g]
8007352003439
20 NR
28.4x24.4x17.9 [cm]
1,287.73 [g]
