Plate 5M BS techn. metallized blue - 14649.73

Pdf

14649.73
Wiring devices / Traditional wiring devices / PLANA / Cover plates

Plate 5M BS techn. metallized blue
5-module cover plate, British Standard, metal, metallized blue

产品状态
2 - Will be discontinued

图纸

Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
5
Mounting direction
Horizontal and vertical
Number of units horizontal
5
Number of units vertical
1
Number of modules horizontal (module system)
5
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Blue
RAL-number (similar)
5014
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
155,00 mm
Height
95,00 mm
Depth
9,00 mm
Built-in width
155,00 mm
Built-in height
95,00 mm
Diameter bore hole (opening)
0 mm

08. ASTA - UK

29. QCERT - Colombia

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352385566
1 NR
15.5x9.5x0.9 [cm]
28.1 [g]
Barcode Qty 10 NR
8007352385573
10 NR
17.7x9.8x10.3 [cm]
338.1 [g]
