TORCIA hand lamp 230V grey - 16450

Pdf
16450

Idea / Devices / Emergency lighting fittings

TORCIA hand lamp 230V grey
TORCIA, electronic hand lamp with high-efficiency LED, supply voltage 230 V~ 50-60 Hz, automatic emergency device, replaceable rechargeable Ni-MH battery, 2 hours of operating, ø 4 mm pins, 19 mm distance between centres + charging socket outlet, grey - 2 modules

  • Can be used as auxiliary lighting in the event of a power failure when inserted in the charger socket, while turning into a normal portable rechargeable hand lamp when removed
  • Power supply: 230 V~ and 4-element replaceable rechargeable Ni-MH 4.8 V 80 mAh battery allowing the use of the device as an emergency light
  • Slide switch to turn the TORCIA hand lamp on and off when it is used as a portable device or to enable or disable the auxiliary lighting function
  • Battery charging time of 48 h and operating time after charging approximately 2 h

产品状态
3 - Active

Class group
Luminaires
Class
Emergency luminaire
Mounting method
Built-in
Monitoring equipment
None
Wiring system
Standby switching
With remote switch connection
No
Power supply system
Peripheral (individual battery)
Battery quality
NiMH
Lamp type
LED not exchangeable
With light source
Yes
Material housing
Plastic
Colour housing
Grey
Material cover
Without cover
Voltage type
AC
Nominal voltage
230,00 - 230,01 v
Degree of protection (IP)
IP40
Protection class
II
Max. system power
1,00 W
Width
49,70 mm
Height/depth
50,10 mm
Built-in width
49,70 mm
Built-in height/depth
39,20 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

最小订单数量: 10 NR

条形码

Barcode Qty 1 NR
8007352002098
1 NR
6x5.4x5.3 [cm]
93.67 [g]
Barcode Qty 10 NR
8007352002197
10 NR
28.1x13.1x6 [cm]
1,013.07 [g]
Barcode Qty 120 NR
8007352657182
120 NR
38.5x29x30 [cm]
12,602.4 [g]
Barcode Qty 2,520 NR
8007352587342
2,520 NR
120x80x105 [cm]
271,650 [g]
