System infrastructure / Enclosures and control units / Switchboards / Shared accessories
Frame 2M for DIN rail
2-module frame for DIN (60715 TH35) rail installation, occupies 2 17,5 mm modules, RAL 7035 grey
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Type of fastening
Other
Other
Mounting method of the module inserts
Back side
Back side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
2
2
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
No
No
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
No
No
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
Yes
Yes
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
最小订单数量: 20 NR
条形码
8007352133402
1 NR
7.7x6.1x5.9 [cm]
28.4 [g]
8007352133419
20 NR
35.5x24.8x8.7 [cm]
728.13 [g]
